WF152D 0.4BG -/+40kPa I2C Digital Pressure Sensors Package LGA4

  • Piezo-resistive silicon micro-machined sensor
  • Gauge type pressure sensor
  • Pressure range: -40..0..40kPa
    (400 hPa / 0.4 Bar / 5.8 Psi / 300 mmHg)
  • Digital Interface: I2C
  • Operating voltage 3.3V
  • Operating mode current: ~1mA (typical)
  • Sleep Mode current: 0.1uA (typical)
  • Absolute accuracy: 0.2~0.5%FS.
  • Pressure Sensitivity: 0.027 Pa/LSB
  • Temperature Compensation: -40℃ ~ 85℃
  • Package Pins: LGA4
  • 24 Bit Σ-Δ ADC
  • RoHS compliant and Halogen-free

Introduction

WF152D series product is the pressure sensor which measures gauge pressures. It consists of a silicon micro-machined sensing element chip and a signal conditioning ASIC. The ASIC is equipped with a 24-bit resolution Σ-Δ ADC and outputs a highly precise pressure value as a digital value.
WF152D series products provides digital output interface. It can achieve ESD robustness, fast response time, high accuracy and linearity as well as long-term stability. All measurement data is fully calibrated and temperature compensated. In addition, it allows for easy system integration.
This series pressure sensor use LGA4 package which is suitable for lots application.

Applications

◼ BPM
◼ Consumer electronics
◼ Household electronic
◼ Industrial monitor and control
◼ Medicine care

Package Dimensions

Dimensions and pin definition (unit: mm)
