WF183DE Digital Pressure Sensor Series

WF183DE Digital Output Pressure Sensors

In Stock

WF183DE is an economical digital pressure-temperature sensor that includes a MEMS pressure sensor and a high-resolution 24-bit ADC and DSP. The WF183DE tire pressure sensor provides high-precision digital outputs of calibrated pressure and temperature through a variety of communication interfaces.

Datasheet: WF183DE Digital Pressure Sensor

Related Resources

WF183DE is factory calibrated for pressure and temperature, so it can be plug-and-play, elimi nating the need for customer calibration.
Variety of communication interfaces can be selected to facilitate MCU selection and reduce the cost of the whole machine.
WF183DE is waterproof up to IP65, which meets the requirements of most waterproof products.
Convenient Inflator Pump, Air Pump Prototype Product, Tire Pressure Monitoring (TPMS) Application Integration

Key Attributes
Pressure Range:	0Kpa~1.5Mpa LGA-8(3.8x3.6) Pressure Sensors, Transducers - Industrial RoHS
Absolute Pressure Accuracy error:	±0.25% FS
Relative accuracy:	±0.03hPa
Temperature accuracy:	± 1.0°C
Temperature Compensation:	-40 ℃ ~ +125 ℃
Waterproof Rating:	IP65
Response Rate:	3~5ms
OverPressure:	3X Damage pressure
Features:	Integrated ADC and digital interface;Standby mode;On-chip calibration and non-volatile storage;On-chip temperature output
Pressure Media is Non-Corrosive Gases Only
RoHS compliant and halogen-free
