WF153A Analog Type Gauge Pressure Sensor
In Stock
WF153A is a analog voltage output pessure sensor,The device consists of a MEMS pressure sensor die mounted on a 3.6x 3.8 mm PCB protected by a metal cap. The WF153A can be delivered in a highly-linear version giving a linear output voltage directly proportional to the applied pressure.
Datasheet: WF153A Analog Pressure Sensor
Related Resources
- Plug-and-forget signal —analog voltage output, one ADC pin and you’re done. No I²C drama.
- Near-perfect linearity —straight-line pressure-to-voltage curve means zero-fuss calibration in firmware.
- Tiny footprint (3.6×3.8mm)—fits where your competitors’ sensors don’t.
- Metal cap protection —MEMS die is shielded from assembly mishaps and environmental abuse. Better yield downstream.
| Key Attributes | |
|---|---|
| Pressure Range: | 0Kpa~40kPa LGA-8(3.6x3.8) Pressure Sensors, Transducers - Industrial RoHS |
| Linearity: | ±0.3%FS |
| Temperature Compensation: | None |
| Zero Point Output Temperature Coefficient | 0.5%FS/℃ |
| Waterproof Rating: | IP65 |
| Response Rate: | 5ms |
| OverPressure: | 2X Damage pressure |
| Burst Pressure: | 4X FS |
| Features: | Measure the force per unit area and convert it into an electrical signal |
| Pressure Media is Non-Corrosive Gases Only | |
| RoHS compliant and halogen-free | |
| Type | Details |
|---|---|
| RoHS | REACH and RHOS |
| ECCN | |
| CNHTS | 9026201090 |
| USHTS | 9026204000 |
| TARIC | 9026208000 |
| CAHTS | 9026200090 |
| BRHTS | 90262010 |
| INHTS | 90262000 |
| MXHTS | 9026.20.99 |
Applications
Automobile Electronic Industry
Home Appliance Industry
Medical and Health Industry
Consumer Electronics Industry
Industrial Monitor and Control Industry
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
