WF155A Analog Pressure Sensor Series

WF155A Analog Type Gauge Pressure Sensor

In Stock

WF155A Series are diffused silicon piezoresistive gauge pressure sensors in an LGA4 package, designed for non-corrosive, non-conductive atmospheric pressure environments. The series offers good repeatability and reliable long-term operational stability, with a compact surface-mount footprint suited for space-constrained PCB designs.

Datasheet: WF155A Analog Pressure Sensor

Related Resources

LGA4 surface-mount package — compact footprint suited for space-constrained PCB designs, with straightforward SMT assembly integration
Good repeatability and long-term stability — suited for applications requiring consistent gauge pressure readings over extended operating periods
Diffused silicon piezoresistive technology — reliable sensing performance in non-corrosive, non-conductive atmospheric pressure media

Key Attributes
Опсег притиска:	0Kpa~40Kpa LGA-4 Pressure Sensors, Transducers - Industrial RoHS
Non-linearity:	±0,3%ФС
Компензација температуре:	Ниједан
Zero Point Output Temperature Coefficient	0.5%FS/℃
Waterproof Rating:	IP65
Стопа одговора:	5ms
OverPressure:	3X Damage pressure
Features:	Measure the force per unit area and convert it into an electrical signal
Pressure Media is Non-Corrosive Gases Only
У складу са РоХС и без халогена
